15.6-inch 4K QFHD IPS 3840-by-2160 or FHD IPS 1920-by-1080 pixels; 60Hz; eDP; LED Backlit Processor: on-board; Intel Core i7-6700HQ (Skylake); 6M Cache VGA Technology: on-board; NVIDIA GeForce GTX 1060 (6GB DDR5); G-Sync; MUX design (switchable between dGPU and iGPU) Mechanical (Frame):brushed aluminium (back cover and bottom case) combined with heavy duty ABS plastic (front cover and top case). Cooling: High performance, high quality copper VGA and CPU heatsinks to keep your system running cool. Memory: Four 260-pin SODIMM sockets; DDR4-2133/2400; 1.2V; up to 64GB Storage: up to 6TB of storage with 4 physical drives: 2x M.2 2280 SSD SATA3 / PCIe x4 and 2x HDD/SSD SATA3 6Gb/s and RAID 0/1 Communications: 1Gb LAN, WLAN, built in antenna for optional 3G/4G/LTE/HSPA Card Reader: 6-in-1: MMC/RSMMC/SD/mini SD/SDHC/SDXC; Push-Push Keyboard and Touchpad: Backlit multi-colour full size 7-colour keyboard with numeric pad; TouchPad with multi-gesture and scrolling; W/A/S/D Gaming key Ports: 2x USB 3.1 Type C; 3x USB 3.0; 2 x mini Display Port 1.3; 1 x HDMI output; 2-in-1 Headphone + S/PDIF; 1 x Microphone-in; 1 x RJ-45 LAN; 1 x DC-in Display Support: Supports up to 4 active internal and/or external displays Operating Systems: Windows 10, 8.1 and 7 Security: Embedded TPM 2.0 Encryption; Fingerprint and Kensington Lock Battery: 4cells Polymer; 60WH; up to 325 minutes in UMA mode Weight: 2.6kg / 5.72lbs Dimensions: WxDxH: 385x271x25.4mm / 15.16x10.66x1.02-inch

Base Configuration   System and Display   EUROCOM Sky M5 R2   Display Calibration   Optional - choose from the options below: Professional Display Calibration with .icc Profile Saved on USB Flash Key [add $68]   Choose your LCD Display   15.6in (39.6cm); 60Hz FHD 1920x1080; Matte; IPS; C/R 700:1; 300cd/m2; NTSC 72%; eDP; 30pin; LG LP156WF6-SPB1 15.6in (39.6cm); UHD; 60Hz; Matte; PLS; 700:1; 16ms; NTSC 72%; eDP; 40pin; Samsung LTN156FL02-101 [add $184]   G-Sync   with G-SYNC (4K Sharp is not supported in G-SYNC)   Processor / CPU   2.60 GHz (up to 3.5) Intel Mobile Core i7-6700HQ; on-board/SMT; 4C/8T; 6MB; 14nm; HD Graphics 530; 45W   Memory Configuration   8GB; 1x 8GB; DDR4; 2400Hz; CL14; 260-pin;1.2V; Kingston HyperX; 1 SODIMM 16GB; 1x 16GB; DDR4-2400; CL14; 260-pin; Kingston HyperX; 1.2V; 1 SODIMM [add $158] 16GB; 2x 8GB; DDR4-2400; CL14; 260-pin; 1.2V; Kingston HyperX; 2 SODIMMs [add $150] 16GB; 1x 16GB; DDR4-2400; 260-pin; 1.2V; 1 SODIMM; G-Skill F4-2400C16S-16GRS [add $158] 24GB; 3x 8GB; DDR4; 2400Hz; CL14; 260-pin; 1.2V; Kingston HyperX; 3 SODIMMs [add $300] 32GB; 4x 8GB; DDR4-2400; CL14; 260-pin;1.2V; Kingston HyperX; 4 SODIMMs [add $450] 32GB; 2x 16GB; DDR4-2400; CL14; 260-pin Kingston HyperX; 1.2V; 2 SODIMMs [add $465] 32GB; 2x 16GB; DDR4-2400; 260-pin; 1.2V; 2 SODIMMs; G-Skill F4-2400C16S-16GRS [add $465] 48GB; 3x 16GB; DDR4-2400; 260-pin; 1.2V; 3 SODIMMs; G-Skill F4-2400C16S-16GRS [add $773] 48GB; 3x 16GB; DDR4-2400; CL14; 260-pin; Kingston HyperX; 1.2V; 3 SODIMMs [add $773] 64GB; 4x 16GB; DDR4-2400; CL14; 260-pin; Kingston HyperX; 1.2V; 4 SODIMMs [add $927] 64GB; 4x 16GB; DDR4-2400; 260-pin; 1.2V; 4 SODIMMs; G-Skill F4-2400C16S-16GRS [add $927]   VGA / GPU Graphics Options   6GB GDDR5; NVIDIA GTX 1060 (N17E-G1); 1280 CUDA; Pascal (16nm); on-board; 75W   Operating System(s)   None - Choose from the options below for Pre-install or install your own Microsoft Windows 10 Home; 64-bit; OEM; USB key [add $153] Microsoft Windows 10 Professional; 64-bit; OEM; with DVD and USB key [add $288] Microsoft Windows 7 Professional 64-bit; OEM; with DVD and USB key [add $307]   Business Productivity Software   None - Choose from the options below Microsoft Office 2024 Home and Student Edition; OEM; MLK; US/Canada [add $138] Microsoft Office 2024 Home and Business Edition; OEM; MLK; US/Canada [add $268]   Keyboard (Language)   US English; QWERTY; Backlit UK English; QWERTY; Backlit [add $77] Alemán / German; QWERTZ; Backlit [add $77] Español / Spanish; QWERTY; Backlit [add $77] Français / French; AZERTY; Backlit [add $77] Italiana / Italian; QWERTY; Backlit [add $77] Norske / Norwegian; QWERTY; Backlit [add $77] Português / Portugese; QWERTY; Backlit [add $77] Svenska / Swedish; QWERTY; Backlit [add $77] Swiss; QWERTZ; Backlit [add $77]   RAID Configuration   None - Choose from the options below: RAID 0 - for maximum performance; 2x M.2 PCIe / SATA are required; NVMe SSD are not RAIDable [add $73] RAID 1 - for Redundancy; 2x M.2 PCIe / SATA are required; NVMe SSD are not RAIDable [add $73]   Internal PCIe NVMe M.2 SSD   Choose your SSD M.2 type 2280 (80x22nm) from the options below: 500GB; M.2; SSD; SATA3; R/W: 560/510MB/s; MICRON / CRUCIAL MX500 [add $153] 250GB; M.2 SAMSUNG 860 EVO; SSD; SATA3; R/W: 550/520 MB/s [add $130] 500GB; M.2; SSD; NVMe 1.4; PCIe 3.0 x4; R/W: 3500/3000 MB/s; SAMSUNG 980 [add $307] 500GB; M.2 SAMSUNG 860 EVO; SSD; SATA3; R/W: 550/520 MB/s [add $253] 1TB; M.2 SAMSUNG 860 EVO; SSD; SATA3; R/W: 550/520 MB/s [add $538]   Internal PCIe NVMe M.2 SSD   Choose your SSD M.2 type 2280 (80x22mm) from the options below: 500GB; M.2; SSD; SATA3; R/W: 560/510MB/s; MICRON / CRUCIAL MX500 [add $153] 500GB; M.2 SAMSUNG 860 EVO; SSD; SATA3; R/W: 550/520 MB/s [add $253] 500GB; M.2 SAMSUNG 980 Pro; SSD; NVMe; R/W: up to 7000/5100MB/s [add $384] 500GB; M.2; SSD; NVMe 1.4; PCIe 3.0 x4; R/W: 3500/3000 MB/s; SAMSUNG 980 [add $307] 1TB; M.2 SAMSUNG 860 EVO; SSD; SATA3; R/W: 550/520 MB/s [add $538] 1TB SSD; SAMSUNG 990 Pro or equivalent depending on availability; PCIe Gen 4.0 x4, NVMe 2.0; M.2 2280; R/W up to 7,450/6,900 MB/s [add $845] 2TB; M.2 SAMSUNG 970 Evo; NVMe PCIe 3.0 x4; SSD; R/W: 3500/2500 MB/s [add $961]   RAID Options: HDD/SSD Storage   None - Choose from the options below RAID 0 setup - for maximum performance [add $58] RAID 1 setup - for full fault tolerance; minimum 2 physical hard drives are required [add $58]   1st Drive: HDD, SSD or SSHD   500GB; SSHD; SATA3; Seagate ST500LM000; 7mm; 2.5in 1TB; 5400rpm; SATA3; Hitachi Travelstar Z5K1000; 7mm; 2.5in [add $8] 2TB; HDD; SATA3; Seagate BarraCuda ST2000LM015; 2.5in 7mm [add $192] 120GB MLC SSD; Intel 530 series; SATA3 6Gb/s; 7mm [add $95] 256GB SSD; MLC; Micron/Crucial; M1100; SATA3 6Gb/s; 7mm [add $92] 250GB SSD; SATA3; 2.5in; 7mm; Samsung 870 EVO; R/W 560/530 MB/s [add $154] 240GB MLC SSD; Intel 530 series; SATA3 (6Gb/s); 7mm [add $195] 500GB SSD; SATA3; 2.5in; 7mm; Samsung 870 EVO; R/W: 560/530 MB/s [add $349] 512GB SATA3 SSD; MLC; Micron M1100 SATA3 (6Gb/s); 7mm [add $308] 800GB SSD; 25nm HET MLC; Intel DC S3700; SATA3 6Gb/s; AES-256; IOPS: 75K (4K Reads), 36K (4K Writes) [add $1426] 1TB SSD; SATA3; Micron 1100; 7mm; 2.5in [add $426] 1TB SSD; Samsung 870 Evo; SATA3; 7mm; 2.5in; MZ-77E1T0B/AM [add $426] 1TB SSD; SATA3; 2.5in; 7mm; Samsung 860 Pro [add $580] 2TB SSD; SATA3; 2.5in; 7mm; Samsung 860 Pro [add $1118] 2TB SSD; Samsung 870 Evo; SATA3; 7mm; 2.5in; R/W: 560/530 MB/s [add $811] 4TB SSD; Samsung 870 Evo; SATA3; 7mm; 2.5in; R/W: 560/530 MB/s [add $1580] *** Without Hard Drive; with HDD bracket included *** [add $10]   2nd Drive: HDD, SSD or SSHD   Choose your 2nd HDD/SSD/SHHD from the options below: 500GB; SSHD; 64MB cache; SATA3 6Gb/s; Seagate ST500LM000; 7mm; 2.5in [add $112] 1TB HDD; 5400rpm; SATA3; Hitachi Travelstar Z5K1000; 7mm; 2.5in [add $119] 2TB; HDD; SATA3; Seagate BarraCuda ST2000LM015; 2.5in 7mm [add $304] 120GB MLC SSD; Intel 530 series; SATA3 6Gb/s; 7mm [add $207] 240GB MLC SSD; Intel 530 series; SATA3 (6Gb/s); 7mm [add $307] 250GB SSD; SATA3; 2.5in; 7mm; Samsung 870 EVO; R/W: 560/530 MB/s [add $265] 256GB SSD; MLC; Micron M1100; SATA3 6Gb/s; 7mm; 2.5 [add $204] 512GB SSD; MLC; Micron M1100; SATA3 (6Gb/s); 7mm [add $422] 500GB SSD; SATA3; 2.5in; 7mm; Samsung 870 EVO; R/W: 560/530 MB/s [add $461] 1TB SSD; MLC; Micron 1100 TLC 3D NAND; SATA3 6Gb/s; 7mm; 2.5-inch [add $538] 1TB SSD; Samsung 870 Evo; SATA3; 7mm; 2.5in; R/W: 560/530 MB/s [add $538] 1TB SSD; SATA3; 2.5in; 7mm; Samsung 860 Pro [add $692] 2TB SSD; Samsung 870 Evo; SATA3; 7mm; 2.5in; R/W: 560/530 MB/s [add $922] 2TB SSD; SATA3; 2.5in; 7mm; Samsung 860 Pro [add $1230] 4TB SSD; Samsung 870 Evo; SATA3; 7mm; 2.5in; R/W: 560/530 MB/s [add $1692]   External Optical Drive   None - Choose from the options below External; 6x Blu Ray (BD-RW) Burner; USB 3.0 [add $307] External; DVD-RW Burner; USB 2.0 [add $115]   Internal Card Reader   6-in-1 Card Reader; SD/MS/MMC/SM/CF/MicroDrive   Security: Biometric Device   Built-in Fingerprint Reader   Embedded Security Chip   Embedded TPM 2.0 Security Chip for Data Encryption   Security Cables / Devices:   None - Choose from the options below Targus - Defcon CL Cable PA410C [add $38] Targus Defcon 1 Alarm Device PPA400C [add $38]   Wireless LAN   2-in-1: 802.11a/b/g/n/ac WLAN+Bluetooth 4.2; Intel Wireless-AC 8260; M.2 2230; up to 867Mbps; 2.4GHz/5GHz 2-in-1: 802.11a/c WLAN + Bluetooth 4.0; Intel Wireless-AC 7265; M.2 2230 [sub $15] 2-in-1; 802.11a/b/g/n/ac WLAN + Bluetooth 4.1; Killer Wireless-AC 1535 [add $15] 2-in-1; 802.11b/g/n + Bluetooth 4.0; Intel Wireless-N 7260; up to 300Mbps; M.2 2230 [sub $23] 2-in-1: 802.11a/b/g/n/ac WLAN+Bluetooth 4.2; Intel Wireless-AC 8265; M.2 2230; up to 867Mbps; 2.4GHz/5GHz [add $15] 2-in-1: 802.11b/g/n WLAN + Bluetooth 4.0 Combo; M.2 2230; Realtek RTL8723BE [sub $31]   TV Tuner (Internal and/or External)   None - Choose from the options below External USB 2.0 TV Tuner; KWORLD UB445 ATSC HYBRID w/REMOTE [add $76] External; USB 2.0; Hauppauge HVR-955Q; ATSC/NTSC/QAM TV Tuner; w/ Remote [add $145]   Built-in Web Camera   2.0 Megapixels; FHD   Choose Extra Battery   None - Choose from the options below 4-cells Smart-Lion Battery [add $127]   Standard AC Adapter   200W AC Adapter; 100-240V; Auto-Switching (Worldwide)   Standard Power Cord - included   USA / Canada EUROPE UK SOUTH AFRICA AUSTRALIA   Extra Power Cord   None - Choose from the options below 2 Extra; US/CANADA [add $29] 1 Extra; USA/CANADA [add $15] 1 Extra; AUSTRALIA [add $15] 2 Extra; AUSTRALIA [add $29] 2 Extra, EUROPE [add $29] 1 Extra; EUROPE [add $15] 1 Extra; SOUTH AFRICA [add $15] 2 Extra; SOUTH AFRICA [add $29] 1 Extra; UK [add $15] 2 Extra; UK [add $29]   Choose Extra AC Adapter   None - Choose from the options below 200W; Auto-switching 100V-250V; Worldwide [add $112]   Carrying Case / Backpack   None - Choose from the options below 18.4in EVERKI ContemPRO; XXL Backpack; EKP117B; 530x420x220mm [add $230] 16in Targus Trademark Notepac Plus Case; Black (CTM400); internal: 14.5x2x11.75in [add $99] 16in Sport Backpack; Heavy-Duty Fabrics with Nylon Webbing Reinforcement; TARGUS TCG650 [add $92] 18in (43.1-45.7cm); Black; Clamshell; Targus CNXL18 Laptop Pro Case [add $145] 17.3in Sport Backpack; Black; Targus Voyager TSB953GL [add $130]   Choose Your Warranty Plan   1 Year Return to Factory Depot with 1 Year of Tech Support 2 Years Return to Factory Depot with 2 Years of Tech Support [add $212] 3 Years Return to Factory Depot with 3 Years of Tech Support [add $307] Options   Graphics Tablet / Stylus   None, Choose from the options below Wacom Intuos Pro;Small; 10.6x6.7in (active 6.3x3.9in); Pen Tablet; PTH460K0A [add $307] Wacom Intuos Pro - Medium; 13.2x8.5in (active 8.7x5.8in); Pen Tablet; PTH660 [add $384] Wacom Intuos Pro - Large; 16.8x11.2in (active 12.1x8.4in); Pen Tablet; PTH860 [add $538] Accessories   External Hard Drive for Data Backup or Network Storage (NAS)   None - Choose from the options below 2TB Buffalo LinkStation 210; 1-Bay NAS Network Attached Storage [add $381] 4TB; BUFFALO LinkStation 720 4TB 2-Bay; Network Attached Storage/NAS Storage/Network Storage/Media Server/File Server [add $612]   Docking Stations, Hubs and Port Replicators   None - Choose from the options below USB 3.0 Hub; 4 Ports; Black Colour; Startech ST4300USB3; 55g/1.94oz [add $61]   Car Adapters and Inverters   None - Choose from the options below 375W DC-to-AC Portable Power Inverter; 2 AC Outlets (US); TRIPP-LITE PV375; US Edition; 120V AC/60Hz; 12V DC; 2.2lbs [add $92]   Cables, Converters and Adapters   None - Choose from the options below: 1 Port USB to Serial RS232 / DB9 Adapter Cable with Optical Isolation; FTDI - FT232RL; Startech ICUSB2321FIS [add $153] 10ft (3m) HDMI to DVI-D Cable M/M; HDMIDVIMM10 [add $53] 1pc DisplayPort to DVi-I Converter Cable for DP port and/or Matrox DH2G or TH2G DP Edition [add $22] 2pcs DisplayPort to DVi-I Converter Cables for Matrox TH2G or DH2G DP Edition [add $45] 3pcs of DisplayPort to DVi-I Converter Cables for Matrox TH2G DP Edition [add $67]   Cables/Adapters for External Monitors; DP; mDP; HDMI; DVI   None - choose from the options below: MiniDP to DVI Dual-Link Active Adapter – USB Powered; MDP2DVID [add $176] DP to DVI Video Adapter M/M; Startech DP2DVIDAP [add $38]
